38V 105Ah LifePO4 Battery For Golf Cart ,lectric Carts,Utility Golf Carts 38.4V Lithium Battery

38V 105Ah LifePO4 Battery For Golf Cart ,lectric Carts,Utility Golf Carts 38.4V Lithium Battery

Choose the ideal LiFePO4 batteries for your golf carts and experience the advantages of enhanced safety, environmental friendliness, and the absence of memory effect. Enjoy worry-free rides powered by our reliable batteries.

Nominal Voltage: 38.4V
Nominal capacity: 72Ah
Working voltage: 2.0V~3.65V
AC impedance resistance(1khz): ≤0.4mΩ

Max. continuous discharge current: 150A

Max. pulse discharge current: 200A/20s
Max. pulse charge current: 70A
Weight: 28kg

Inquiry

Overview
Parameter
Inquiry
Related Products

Power Your Life Anywhere ,Anytime !

LiFePO4 Golf Car High Power Battery 48V 51.2V 150Ah 48 Volt Lithium Deep Cycle <a class='inkey' href='https://www.lifepo4-power.com/Golf-cart-batteries' target='_blank'>Golf Cart Batteries</a> factory

Compared to traditional AGM/lead-acid batteries, LiFePO4 batteries (Lithium Iron Phosphate batteries) offer several advantages:

Plug-and-play design: Easily convert your golf cart from using 6-6V lead batteries to just one 36V lithium battery, or from 8-6V lead batteries to a single 48V lithium battery.
Built-in Battery Management Systems (BMS): Our batteries come equipped with comprehensive protection functions and efficient BMS, ensuring maximum performance and safety.
Increased Power Storage: LiFePO4 batteries provide over 50% more power storage compared to lead-acid batteries, resulting in greater mileage and extended range.
Lightweight and Compact: By utilizing the latest LiFePO4 technology, our lithium golf cart batteries are 70% lighter and 50% smaller than traditional lead-acid batteries.
Extended Lifespan: Enjoy a lifespan that is six times longer than that of lead-acid batteries, with an impressive expectancy of up to 6000 cycles.

Upgrade your golf cart experience with LiFePO4 batteries and enjoy the benefits of convenience, power, longevity, and compactness.

Electrical Specifications

Nominal Voltage	38.4V
Rated Capacity	105Ah
Energy	4032Wh
Opetation Voltage	26.4V-43.8V
Self Discharge	3% / per month
Efficiency	99%
Max Module In Series	1 (Single Use)
Max Module In Parallel	10pcs
Short Circuit Protection	200-800µs Auto recover or charge release

Discharge/Charge Specifications

Max Continuous Discharge current	250A
Peak Current	260A (120s)
Discharge Pluse Current	520A/20S
Discharge Cut-off Voltage	26.4V (2.2V±0.05v) pc)
Max Charge Current	100A
Recommended Charge Current	10A-50A
End of Charge voltage	43.8V±0.2V
BMS Over Charge Voltage Cut-off	45V(3.75V±0.05v pc)
Balancing Voltage	3.6V±0.05v pc
Cell Balancing current	Support

Mechanical Specifications

Terminal Type	2*M8 Bolts
Weight	32kg
Case Dimension (LWH)
Case Material	Powder Coated Steel
Enclosure Protection	IP65
Cell Type/Chemistry	Prismatic-LiFePO4 battery
BMS Functions:Low voltage ,high voltae,over temp ,over current,short-circuit protection, passive balance function,etc.

Temperature Specifiactions

Discharge Temperature	-20～+65℃
Charge Temperature	-20～+45℃
Storage Temperature Range	-20～+45℃
Battery High Temperature Protection	YES
BMS Temperature Protection	YES
